8.5 Parameters
FIDAMAT 6
98 Operating Instructions, 01/2019, A5E00222135-04
This is the case:
● During the warm-up phase
● After entry of the code (i.e. change to "Operator control mode")
● When remote control via the interface (ELAN, PROFIBUS) is used
● During automatic calibration (Autocal) or remote calibration
Note
Control function ("CTRL")
When the function control is active, the measured value can be false!
As long as you are in code level 1 or 2, thus in "Operator control mode", the function
control is active. If you have configured the analog output with "Store on" under
function
77, this remains in fault current state until you remove it because any code level
Table 8- 3 Status messages
What appears in the display depends on functions 52 and 53
Function 52 "□"
Function 53 "■"
Function 52 "■"
Function 53 "■"
Calibration: CAL None CAL □ CAL ■ CAL; calibration running (also in
Stored value:
None STO □ STO ■ STO; analog output is stored (see
Limit: LIM None LIM □ LIM ■ LIM; limit has been violated (see
Autorange AR None AR □ AR ■ AR; measuring range switching
(actively possible), see function 40
Control function:
CTRL
None □ CTRL or ■ CTRL
(function control
cannot be
switched off using
function 52)
□ CTRL ■ CTRL; device is in the "Warm-up
phase" operating state or in "Opera-
tor control mode" or calibration is in
progress or a remote control via the
interface (ELAN, PROFIBUS) is
If an error occurs during operation, the message "Maintenance request", "Fault" or
"Measurement protection" appears in the status line, depending on the severity of the error.
This message is alternately displayed with the status messages.
In addition, when communication is over the ELAN interface, the message "Remote" is
displayed – also alternating – with display of the device status.
See also
Select measuring ranges (function 40) (Page 90)
Limits (function 51) (Page 95)
Analog output memory (function 77) (Page 119)
