Technical specifications
11.3 Technical data of the FIDAMAT 6-G
FIDAMAT 6
170 Operating Instructions, 01/2019, A5E00222135-04
Table 11- 11 Technical specifications – Pressures and flow
Pressures and flow
Gases
Inlet pressure hPa
(rel.)
Operating pressure
hPa (rel.)
Flow through FID
ml/min
Flow through by-
pass
ml/min
Without pump
start-up
With pump start-
up
Combustion gas
2000 ... 4000
1000 ± 20
~ 12
-
Combustion air
2000 ... 4000
420 ± 20
500
~ 320
~ 500
Sample gas
atmospheric
-
500 ± 2
~ 3
~ 1000
Zero gas 2500 ... 3000 - 500 ± 2 ~ 3 ~ 1000
Calibration gas 2500 ... 3000 - 500 ± 2 ~ 3 ~ 1000
11.3 Technical data of the FIDAMAT 6-G
Table 11- 12 Technical specifications – General
General
Measuring ranges 4, internally and externally switchable;
manual and automatic measuring range switchover possible
Automatic measuring range switchover
Hysteresis, selectable
Smallest possible span
0-10 ppm
Detection limit
0.03 ppm
Largest possible span
99.999 ppm
Concentration units (ppm)
C1, C3, C6, mg C/m3
Measured value display Digital concentration display (5 digits with floating decimal
point)
Resolution of digital display
0.1% of measured value
Operating position
Front panel vertical
Conformity
CE marking EN 50081-1, EN 50082-2
Oven temperature Adjustable between 100 and 200 °C (depending on applica-
tion)
Table 11- 13 Technical specifications – Gas inlet conditions
Gas inlet conditions
Permissible sample gas pressure
Approx. 1,000 hPa
Sample gas flow rate
18 to 60 l/h (0.3 to 1 l/min)
Sample gas temperature
0-200 °C
Sample gas humidity
< 90% relative humidity
