Service and maintenance
9.10 Other faults
FIDAMAT 6
142 Operating Instructions, 01/2019, A5E00222135-04
Thermal cut-out has trig-
gered
• Defect of the electronic
heating control
• Overshooting of the max-
imum permissible oven
temperature
• The triggering of the thermal
cut-out signals a defect of the
electronic heating control.
The device is no longer
ready for operation and
a re-
pair must be carried out be-
fore starting up again.
The thermal cut-out itself can
be manually reset. After the
triggering, the sensor tem-
perature must fall by
20 °C before a reset is pos-
sible by means of the reset
button on the front panel.
S10
24 h RAM/Flash
check
RAM/Flash defective Replace motherboard
S12
Q
Line voltage supply Line voltage supply outside
tolerance
Bring the line voltage within the
specified tolerance limits accord-
S13
Q
Hardware Internal supply outside toler-
ance
• Check diagnostic values
• Replace motherboard /
adapter board
S14 Measured value >
full-scale value of
characteristic
Measured value is greater
than full-scale value of
characteristic
(+5%)
• Incorrect calibration
• Wrong calibration gas
• Sample gas concentra-
tion too high
• Repeat calibration
• Check calibration gas
• Check measuring range
S15
Calibration aborted Operation was aborted dur-
ing an AUTOCAL
See also
Relay outputs (function 71) (Page 107)
Binary inputs (function 72) (Page 109)
Save / load data (function 75) (Page 116)
Error on/off (function 87) (Page 127)
Start-up state (function 91) (Page 128)
9.10 Other faults
Regularly calibrate the device at the zero point (function 20) and span (function 21) with the
corresponding calibration gases in accordance with the drift data. Make sure the gases are
purified properly.
A larger zero drift is usually a sign that residues or dust particles have deposited in the FID.
