FIDAMAT 6
Operating Instructions, 01/2019, A5E00222135-04
167
Technical specifications
11
11.1 General technical data of the FIDAMAT 6 gas analyzers
Table 11- 1 Technical specifications – Design, housing
Design, enclosure
Degree of protection IP20 according to EN 60529
IP40 after installation in analyzer cabinet (FIDAMAT Analyzer System)
Dimensions
See section "Dimension drawings and circuit diagrams" (Page 173)
Weight
approx. 23 kg (51 lbs.)
Table 11- 2 Technical specifications – Electric characteristics
Electrical characteristics
Auxiliary power supply 100 to 120 V AC (nominal range of use 90 V to 132 V), 48 to 63 Hz or
200 to 240 V AC (nominal range of use 180 V to 264 V), 48 to 63 Hz
Power consumption Approx. 150 VA during operation
Approx. 350 VA in the warm-up phase
EMC interference immunity (electromagnetic
compatibility)
In accordance with standard requirements of NAMUR NE21 (08/98)
Electrical safety In accordance with EN 61010-1,
Overvoltage category II
Fuse values 100 to 120 V: 4.0 T/250
200 to 240 V: 2.5 T/250
Table 11- 3 Technical specifications – Gas consumption data
Gas consumption data
Combustion air
Approx. 350 ml/min
Hydrogen
Approx. 12 ml/min
Sample gas
Approx. 1 l/min
Zero gas/ calibration gas
Approx. 1.5 l/min
Table 11- 4 Technical specifications – Time response
Time response
Warm-up time (until ready for measurement)
Approx. 3 h at room temperature
Display delay (T90)
2-3 s
