Functions
8.5 Parameters
FIDAMAT 6
Operating Instructions, 01/2019, A5E00222135-04
97
Suppress negative measured values for
55
Lock logbook 60
Suppress negative measured values
Fault/ Maint. A/ CTRL/ NAMUR
Signal tolerance violation
Temperature post-compensation of the
86
Temperature post-compensation of the
86
Automatic setting of AUTOCAL for
PROFIBUS
(firmware version 1.3.5 or higher)
None When a PROFIBUS option card is installed,
the following operating modes of AUTOCAL
(function 24) are set when the device is re-
started:
• 'AUTOCAL/Check' ON;
• 'Start cyclically' OFF
• "Start via binary input" OFF
Besides the functions listed in this section, function 52 can also be used to activate other
service functions. These are restricted to service engineers and are only visible when the
service code is entered (code level 3).
8.5.5 Status messages (function 53)
Figure 8-28 Status messages
With this function, you can configure the display of status messages in the status line of the
measured value display. You can display a maximum of three different status messages.
The message CODE ■/□ provides information on the current operating mode ("Coded
display mode"/"Decoded display mode") and is therefore always displayed.
The device activates the function control (softkey 5 in the function display) when it
determines that the measured value was influenced.
