LMVSeriesTechnicalInstructions 

DocumentNo.LV5‐1000

SCCInc. Page31 Section6



MethodshowninFigure6‐13:



PressureP1relativetopressureP2(differentialpressureacrosstheFGRdamper)ismoreconstantwith

firingrate.DifferentialpressurewillbegeneratedacrosstheFGRdamperatlowfirebyusingthe

suctionofthebloweragainsttheairdamper.ThedifferentialpressureacrosstheFGRdampercanalso

beadjustedwiththespeedoftheVFD.Asfiringrateincreases,P2willincrease(lessvacuum)andP1

willincreaseduetoincreased

pressurebehindthestackdamper,yieldingamoreconsistentdifferential

pressure.Asaresult,theFGRdampercanbesizedmoreappropriatelyandshouldofferbettercontrol.

Otherpointstoconsider:



1. IfusingO

trim,theeffectthatthetrimhasonFGRflowcanbeadjusted.Threepossibilities:



a. Ifonlytheairdamperistrimmed(setto“airinfluenced”), trimmingclosedandreducingairflow

willincreasethevacuumatP2andincreaseFGRflowrelativetoairflow.



b. IfonlytheVFDistrimmed(setto“airinfluenced”),trimmingslowerandreducingairratewill

reducetheva

cuumatP2andreducetheFGRflowrelativetotheairflow.



c. Ifboththeairdamper andVFDaretrimmed(setto“airinfluenced”),trimmingclosedshould

keepthevacuumatP2relativelyconstantandkeeptheFGRflowconstantrelativetotheair

flow.



2. DifferentialpressureacrosstheFGRdamperissignificantevenatlowfiredu

etothevacuum

providedbytheblower.SmallchangesinthedifferentialpressureacrosstheFGRdamperwillcause

smallchangesinFGRflow.FGRflowwillbemorerepeatableascomparedtothemethodinFigure

6‐12,

especiallyatlowtomidfire.



3. Nofixedairdampersexistfortheblowerintake,andthefixeddamperinthestackmaybeableto

beopenedfurther,reducingtheblowerpressurerequirements.


