LMVSeriesTechnicalInstructions 

DocumentNo.LV5‐1000

SCCInc. Page5 Section7



CANbusFaultsIncluding“AZLnotonBus”and“SystemTest”(continued)



 MakesuretheshieldingoftheCANbuscableisgroundedproperly.Theshieldingof

theCANbuscableisimmediatelyundertheplasticsheathingandencirclesallfive

conductors.TheshieldingonallsegmentsoftheCANbuscablemusthavecontinuity

withterminalX51.1.Thiscanbecheckedwithamulti‐meterbyconnectingone

probeontheAGG5.110shieldingclipattachedtoterminalX51.1,andtheother

probeonthelastactuator(orO

module)ontheCANbusnetwork.



 Ifeverythingelsechecksout,andeverytimeoneoftheactuatorsispluggedinit

immediatelycausesaCANbusfault,replacetheappropriateactuator.


