Siemens LMV5 Series Technical Instructions

LMV Series Technical Instructions
Document No. LV5-10
00
SCC Inc. Page 19 Section 1
Typical LMV52 System for a Cleaver Brooks Retrofit
Components for a typical LMV52 retro
fit on a Cleaver Brooks boiler are listed below:
Control Panel Components
1
LMV52.240B1
Dual fuel burn
er control, fuel
-
air ratio control, VFD control, O
2
trim
1
AGG5.210
120 VAC to (3) 12 VAC transformer
1
AZL52.40B1
Display with Modbus port, PC port, six languages available
1
AGG5.635
Pre
-
made 9
foot cable connecting an LMV5 to the AZL display
1
AGG5.720
Base plug set with all terminals for a typical LMV5 system
1
AGG5.110
Strain relief and actuator CANbus grounding
2
BR
-
LMV5
Brackets for mounting an LMV5 in an electrical enclosure
Air Damper Assembly
1
SQM48.497
B
9
Actuator, 177 in
-
lb torque, 14mm keyed shaft, 30
-
120 sec running time
1
BR
-
48CB
AIR
CB air damper bracket retrofit kit for SQM48 actuator
Gas Firing Rate Control Valve
1
VA45.2
-
NF
-
300
SQM45.295
B
9 to 3” full port VKG butterfly
valve assembly
Oil Firing Rate Control Valve
1
SQM45.295
B
9
Actuator, 27 in
-
lb torque, 10mm “D” shaft, 10
-
120 sec running time
1
BR
-
45
CBOIL
CB fuel oil controller bracket retrofit kit for SQM45 actuator
Actuator Accessories
1
AGG5.643
(100)
100’ roll
of CANbus cable
1
1
ADP
-
M16XE500
(5)
ADP-M16XE500-LONG(5)
5
-
pack of M16 to 1/2”
NPSM metal conduit adapters
5-pack of long M16 to 1/2” NPSM metal conduit adapters
Flame Scanner
1
QRI2A2.B180B
Self
-
check infrared flame scanner, forward viewing
Flame Scanner Accessories
1
AGG2.110
Kit for mounting forward viewing QRI… flame scanner on a flame tube
1
AGG2.120
Pg9 to 1/2” NPSM conduit connection adapter for QRI… flame scanner
Sensors
1
7MF1565
-
4BE00
-
5EA1
Pressure sensor, 0
-
30 PSI, 4
-
20 mA signal
1
QAC22
1000 Ohm, 2
-
wire, nickel RTD for ambient air temperature
1
QAM
-
P210
1000 Ohm, 2
-
wire, platinum RTD for
flue gas
temperature
Variable Frequency Drive (VFD) Components
1
AGG5.305
Speed sensor and associated mounting kit for VFD control
O
2
Trim Components
1
PLL52.110A100
CANbus module to connect QGO O
2
sensor to LMV52
1
QGO20.000D17
O
2
sensor with zirconium dioxide measuring cell
1
AGO20.002LDS
-
KT
Weldless flue gas collector for stacks 18
-
36” in diameter
1
C8120(35)
6
-
conductor shielded
cable to connect the O
2
module and O
2
sensor
