Siemens LMV5 Series Technical Instructions

Technical Instructions LMV Series
Document No. LV5-100
0
Section 1 Page 20 SCC Inc.
LMV5 SYSTEM ORDER SHEET
Email: customerservice@scccombustion.com Fax: (224) 366-8455
Company
Name
PO#
Required
Ship Date
Ship To
Address
Shipping
Method
Description Part Number Qty
Control Panel Components
Base Unit (Qty 1 Required)
Float/bump LMV51.040C1
Load control LMV51.140C1
VFD/O
2
trim/fuel meter LMV52.240B1
Advanced O
2
trim LMV52.440B1
Transformer (Qty 1 or 2 Required) 120V to (3) 12V transformer AGG5.210
Display Unit (Qty 1 Required) Display unit w/ Modbus AZL52.40B1
Display Cable (Qty 1 Required) 9' AZL to LMV5 cable AGG5.635
Plug Set (Qty 1 Required)
Typical base plug set AGG5.720
Maximum system plug set AGG5.7COMPLETE
Strain Relief (Qty 1 Required) For CANbus grounding AGG5.110
Touchscreen Kit (Optional)
Write in part number
(see Doc. No. TS-1000)
LMV5 Mounting Brackets
(Qty 2 Recommended)
For electrical enclosure BR-LMV5
Control Panel Spare Parts (Optional)
120V main fuse FUSE6.3A-SLOW
12V CANbus fuse FUSE4.0A-SLOW
5 pack of 4-pins 1840382(5)
5 pack of 5-pins 1840395(5)
3 pack of 6-pins 1840405(3)
Transformer plugs AGG5.2PLUGS
Spark quencher XEB0471
RS-232 to RS-485 converter kit TS-5X-KT
Air Damper Assembly
Actuator (Qty 1 Required)
27 in-lb, 10mm "D" SQM45.295B9
177 in-lb, 14mm keyed SQM48.497B9
310 in-lb, 14mm keyed SQM48.697B9
600 in-lb, 25mm keyed SQM91.391A9
Coupling (Qty 1 Required)
Write in part number
(see Doc. No. CPBK-1000)
Mounting Bracket Kits (Optional)
Write in part number
(see Doc. No. CPBK-2000)
Cleaver Brooks Retrofit Kits (Optional)
Kit for SQM48 BR-48CBAIR
Kit for SQM45 BR-3345CBAIR
Lucoma Air Damper Mounting Brackets
(Optional)
Kit for SQM48 BR-SQM48-LUC
Kit for SQM45 BR-SQM3345-LUC
Gas Firing
Rate Valve
Valve Actuator Assemblies
(Qty 1 Required if Firing Gas)
Write in part number
(see Doc. No. VA-1000 or VA-
3000)
