Device Display Meaning for the LMV5x System Corrective Action
Any # Stack error
01 Stack overflow
02 Value dropped below preset minimum limit
03 Test values in stack range exceeded
53 01 Faulty reset state has occurred
Any # Invalid parameter setting. See corrective action based on diagnostic code.
00
AND NOT ("& /") settings are not permitted in the gas
extraneous light phases
Correct the setting for the SensExtralGas parameter.
01
AND NOT ("& /") settings are not permitted in the oil
extraneous light phases
Correct the setting for the SensExtralOil parameter.
02
AND NOT ("& /") settings are not permitted in the gas pilot
phases
Correct the setting for the SensPilotPhGas parameter.
03
AND NOT ("& /") settings are not permitted in the oil pilot
phases
Correct the setting for the SensPilotPhOil parameter.
04
AND NOT ("& /") settings are not permitted in the gas operating
phases
Correct the setting for the SensOperPhGas parameter.
05
AND NOT ("& /") settings are not permitted in the oil operating
phases
Correct the setting for the SensOperPhOil parameter.
06
The temperature-compensated flue gas recirculation function is
not permitted
This function is only enabled for the LMV52.4. Setting
FGR-Mode to Temp.comp, TCautoDeact, deactMinpos,
or auto deact. is not permitted.
07 The high-temperature flame safeguard function is not permitted
This function is only enabled for the LMV50. Setting
to "HTempGuard" is not permitted.
08 The external flame safeguard function is not permitted
This function is only enabled for the LMV50 and
LMV52. Setting HeavyOilDirStart to "ext.FlameGd" is
09 The flue gas recirculation function is not permitted
This function is only enabled for the LMV50, LMV51.3,
and LMV52. Changing FGR-Mode from "deactivated"
0A The VSD / auxiliary actuator 3 function is not permitted
This function is only enabled for the LMV50, LMV51.3,
and LMV52. Setting AuxActuator to VSD and / or
0B The cooling in standby function is not permitted
This function is only enabled for the LMV50. Setting
to "CoolfctStby" is not permitted.
0C
X5-03 double assignment: External load controller via contact
(operating mode 1) / deactivation O2 and startup stop phase 36
Adjust LC_OptgMode or Config X5-03 to prevent the
double assignment.
Fault with Base Unit (LMV5)
52
If fault occurs sporadically, reduce electrical noise.
If fault occurs continuously, replace LMV5.
LMV5
Internal Fault
Basic Unit
Invalid
parameterization
57
Section 7 Page 37 SCC Inc.
