Siemens LMV5 Series Technical Instructions

LMV Series Technical Instructions
Document No. LV5-10
00
SCC Inc. Page 5 Section 8
Table of addresses
Function Address Number
of words
Data designation Access Data
format
Data type /
coding
Rang
e Updating
rate
03/04
0
1
Phase
R
U16
0...255
Fast
03/04 1 1 Position of currently active fuel actuator R S16 Degrees -3... 93° Fast
03/04 2 1 Position of gas actuator R S16 Degrees -3...93° Fast
03/04 3 1 Position of oil actuator R S16 Degrees -3...93°
Fast
03/04 4 1 Position of air actuator R S16 Degrees -3...93°
Fast
03/04 5 1 Position of auxiliary actuator 1 R S16 Degrees -3...93°
Fast
03/04 6 1 Position of auxiliary actuator 2 R S16 Degrees -3...93°
Fast
03/04 7 1 Position of auxiliary actuator 3 R S16 Degrees -3...93°
Fast
03/04 8 1 Manipulated variable for variable speed drive R S16 Percent 0…110 % Fast
03/04 9 1 Current type of fuel R U16 0= Gas
1= Oil
0...1 Fast
03/04
10
1
Current output
R
U16
Fire rate
0…100 %
Fast
03/04
11
1
Current setpoint / temperature / pressure
R
U16
Process units
Medium
03/04 12 1 Actual value / temperature / pressure
Unit: See address 18 / 19
R U16 Process units 0…2000 °C
0…100 bar
Medium
03/04 13 1 Flame signal R U16 Percent 0…100 % Medium
03/04 14 1 Current fuel throughput R U16 0..65534 Fast
03/04
15
1
Current O2 value (LMV52...)
R
U16
Percent
0…100 %
Fast
03/04 16 1 Volume unit of gas R U16 0= m³
1= ft³
0…1 Slow
03/04 17 1 Volume unit of oil R U16 0= l
1= gal
0…1 Slow
03/04 18 1 Unit of temperature R U16 0= °C
1= °F
0…1 Slow
03/04 19 1 Unit of pressure R U16 0= bar
1= psi
0…1 Slow
03/04 20 1 Sensor selection R U16 0=Pt100
1=Pt1000
2=Ni1000
3=temp. sensor
4=press. sensor
5=Pt100Pt1000
6=Pt100Ni1000
7=no sensor
0…7 Slow
03/04 21, 22 2 Startup counter total R S32 0…999999 Slow
03/04 23, 24 2 Hours run counter R S32 0…999999 Slow
03/04 25 1 Current error: Error code R U16 0...0x FF Fast
03/04 26 1 Current error: Diagnostic code R U16 0…0x FF Fast
03/04 27 1 Current error: Error class R U16 0...5 Fast
03/04 28 1 Current error: Error phase R U16 0...255 Fast
03/04 29 1 Temperature limiter OFF threshold, in
degrees Celsius / Fahrenheit
(in address 129: Temperature limiter
switching differential ON)
R U16 0…2000 °C
32…3632 °F
Slow
03/04 30 1 Supply air temperature, in degrees Celsius /
Fahrenheit (LMV52...)
R U16 -100…+923 °C
-
148..+1693 °F
Slow
03/04 31 1 Flue gas temperature, in degrees Celsius /
Fahrenheit (LMV52...)
R U16 -100...+923 °C
-
148...+1693 °F
Slow
03/04
32
1
Combustion efficiency (LMV52...)
R
U16
Percent
0...200 %
Slow
