Siemens LMV5 Series Technical Instructions

Technical Instructions LMV Series
Document No. LV5-100
0
Section 8 Page 6 SCC Inc.
Function
Address Number of
words
Data designation Access Data type / coding Range Updating
rate
03/04 35 1 Inputs (bits) R U16 - Medium
Coding: 0 → inactive 1 → active
B15 B14 B13 B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1 B0
B8
B9
B10
Safety loop
Pressure switch-min-gas
B0
B1
B2
Controller ON/OFF
Fan contactor contact
Fuel selection oil
B11 Pressure switch-max-gas B3 Fuel selection gas
B12 B4
B13 Air pressure switch B5 Pressure switch-max-oil
B14 Start release oil B6 Pressure switch-min-oil
B15 Heavy oil immediate start B7 Pressure switch – valve proving
Function Address Number of
words
Data designation Access Data type /
coding
Rang
e Updating rate
03/04 37 1 Outputs (bits) R U16 - Medium
Coding: 0 → inactive 1 → active
B15 B14 B13 B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1 B0
B8 Fuel valve SV oil B0 Alarm
B9 Fuel valve V1 oil B1
B10 Fuel valve V2 oil B2
B11 Fuel valve V3 oil B3
B12 Fuel valve SV gas B4 Ignition
B13 Fuel valve V1 gas B5 Start signal / 3-way solenoid valve
B14 Fuel valve V2 gas B6 Fan
B15 Fuel valve PV gas B7 Oil pump / magnetic coupling
Function Address Number
of words
Data designation Access Data
format
Data type /
coding
Range Updating
rate
R 03/04
W 06/16
38 1 Program stop R/W*
EEPROM
U16
0=deactivated
1=24 PrePurgP
2=32 PrePFGR
3=36 IgnitPos
4=44 Interv 1
5=52 Interv 2
6=72 PostPPos
7=76 PostPFGR
0...7 Slow
R 03/04
W 06/16
39 1 Operating mode with load controller
R/W*
EEPROM
U16 0=ExtLC X5-03
1=IntLC
2=IntLC Bus
3=IntLC X62
4=ExtLC X62
5=ExtLC Bus
0…5 Slow
R 03/04 40 1 Selection of manual or automatic operation R
U16 0=automatic
1=burner on
2=burner off
0…2 Fast
R 03/04
W 06/16
41 1 Modbus mode: Local / Remote R/W U16 0 = Local
1 = Remote
0…1 Slow
