Siemens LMV5 Series Technical Instructions

LMV Series Technical Instructions
Document No. LV5-10
00
SCC Inc. Page 7 Section 8
Function Address
Number
of words
Data designation Access Data
format
Dat
a type /
coding
Range Updating
rate
R 03/04
W 06/16
42 1 Modbus downtime:
Max. time with no communication. When this
time has elapsed, automatic changeover from
Remote to Local takes
place
R/W*
EEPROM
U16 0…7200 s Slow
R 03/04
W 06/16
43 1 Operating mode in Remote mode.
Auto, Remote ON, Remote OFF
R/W U16
0 = Auto
1 = ON
2 = OFF
0…2 Fast
R 03/04
W 06/16
44 1 External setpoint W3
Unit: See address 18 / 19
R/W
2
U16
Process units See ”Data types”
on page 10
Fast
R 03/04
W 06/16
45 1 Predefined output mod. / multistage R/W
U16 Fire rate See ”Data types”
on page 10
Fast
R 03/04
W 06/16
46 1 Fuel selection AZL... R/W*
EEPROM
U16
0 = Gas
1 = Oil
0…1 Slow
R 03/04
W 06/16
47 1 Setpoint W1 R/W
1, 2
EEPROM
U16
Process units See ”Data types”
on page 10
Slow
R 03/04
W 06/16
48 1 Setpoint W2 R/W
1, 2
EEPROM
U16
Process units See ”Data types”
on page 10
Slow
R 03/04
W 06/16
49 1 Weekday R/W U16
0 = Sunday
1 = Monday
...
0…6 Slow
R 03/04
W 16
50-52 3 Date R/W U16[3] Data structure
Date
Slow
R 03/04
W 16
53-55 3 Time of day R/W U16[3] Data structure
Time of day
Slow
R 03/04
W 16
56, 57 2 Hours run gas (adjustable to zero only)
R/W*
EEPROM
S32 0...999999 h Slow
R 03/04
W 16
58, 59 2 Hours run oil stage 1 or modulating
(adjustable to zero only
)
R/W*
EEPROM
S32 0...999999 h Slow
R 03/04
W 16
60, 61 2 Hours run oil stage 2 or modulating
(adjustable to zero only
)
R/W*
EEPROM
S32 0...999999 h Slow
R 03/04
W 16
62, 63 2 Hours run oil stage 3 or modulating
(adjustable to zero only
)
R/W*
EEPROM
S32 0...999999 h Slow
R 03/04
W 16
64, 65 2 Hours run total (adjustable to zero on
ly) R/W*
EEPROM
S32 0...999999 h Slow
03/04 66, 67 2 Hours run total (read only) R S32 0...999999 h Slow
03/04 68, 69 2 Hours run device connected to power
(read only)
R S32 0...999999 h
Slow
R 03/04
W 16
70, 71 2 Startup counter gas (adjustable to zer
o only) R/W*
EEPROM
S32 0...999999 Slow
R 03/04
W 16
72, 73 2 Startup counter oil (adjustable to
zero only) R/W*
EEPROM
S32 0...999999 Slow
R 03/04
W 16
74, 75 2 Startup counter total (adjustable t
o zero only)
R/W*
EEPROM
S32 0...999999 Slow
03/04 76, 77 2 Startup counter total (read only) R S32 0...999999 Slow
03/04 78, 79 2 Fuel volume gas (read only)
(resettable from AZL5... version V4.10)
0…199999999.9 m³
0…1999999999 ft³
R/W*
EEPROM
S32 See ”Data types”
on page 10
Slow
1. Can only write to setpoint W1 or W2 if in mode “IntLC Bus”, otherwise it is ignored.
2. When in mode “IntLC Bus”, setpoints W1, W2, and W3 will be affected by parameters Ext MinSetpoint and Ext MaxSetpoint.
