Siemens LMV5 Series Technical Instructions

Technical Instructions LMV Series
Document No. LV5-100
0
Section 8 Page 8 SCC Inc.
Function Address
Number
of words
Data designation Access Data
format
Data type /
coding
Range Updating
rate
03/04 80, 81 2 Fuel volume oil (read only)
(resettable from AZL5... version V4.10)
0…199999999.9 l
0…199999999.9 gal
R/W*
EEPROM
S32 See ”Data types”
on page 10
Slow
03/04 82 1 Number of lockouts R U16 0…65535 Slow
03/04 83 1 Extra temperature sensor
(from AZL5... version V4.10 or later)
R U16 °C:
°F:
0..2000 °C
32..3632 °F
Slow
Parameters 84...137 are available
on
AZL5... version V4.20
or
later
03/04 84-91 8 AZL5... ASN R U8[16] String Constant
03/04 92 1 AZL5... parameter set code R U16 Constant
03/04 93 1 AZL5... parameter set version R U16 Constant
03/04 94-96 3 AZL5... identification date R U16[3] Date Constant
03/04 97 1 AZL5... identification number R U16 Constant
03/04 98-105 8 Burner control ASN R U8[16] String Constant
03/04 106 1 Burner control parameter set code R U16 Constant
03/04 107 1 Burner control parameter set version R U16 Constant
03/04 108-110 3 Burner control identification date R U16[3] Date Constant
03/04 111 1 Burner control identification number R U16 Constant
03/04 112 1 Software version AZL5... R U16 Hexadecimal Constant
03/04 113 1 Software version burner control R U16 Hexadecimal Constant
03/04 114 1 Software version load controller R U16 Hexadecimal Constant
03/04 115-122 8 Burner identification R U8[16] String Upon
reset
03/04 123 1 Min-output gas R U16 Fire rate 0...100 %
Slow
03/04 124 1 Max-output gas R U16 Fire rate 0...100 %
Slow
03/04 125 1 Min-output oil R U16 Fire rate 0...100 %
1001...
1003
Slow
03/04 126 1 Max-output oil R U16 Fire rate 0...100 %
1001...
1003
Slow
R 03/04
W 16
127 1 Load limitation enduser (modulating)
R/W*
EEPROM
U16 Fire rate 0...100 % Slow
R 03/04
W 16
128 1 Load limitation enduser (multistage)
R/W*
EEPROM
U16 0: S1
1: S2
2: S3
0...2 Slow
03/04 129 1 Temperature limiter switching differential ON
(in address 29: Temperature limiter OFF
threshold, in degrees Celsius / Fahrenheit)
R S16 Percent
-50...0 % Slow
03/04 130 1 Measuring range temperature sensor R U16 0: 150°C / 302°F
1: 400°C / 752°F
2: 850°C / 1562F
0...2 Slow
03/04 131 1 Adaption active / inactive R U16 0: Inactive
1: Active
0...1 Fast
03/04 132 1 Adaption state R U16 Adaption list 0...12 Slow
R 03/04
W 16
133 1 Start adaption R/W U16
0: Reset value
1: Start
2: Abort
0...2 Slow
R 03/04
W 16
134 1 Adaption output
Permissible values: 40%, 50%, 60%,
70%, 80
%, 90%, 100%
R/W*
EEPROM
U16 Percent 40...100 % Slow
R 03/04
W 16
135 1 P-value R/W*
EEPROM
U16 Percent 2...500 % Slow
R 03/04
W 16
136 1 I-value R/W*
EEPROM
U16 Seconds 0...2000 s Slow
