Siemens LMV5 Series Technical Instructions

LMV Series Technical Instructions
Document No. LV5-10
00
SCC Inc. Page 9 Section 8
Function Address
Number
of words
Data designation Access Data
format
Data type /
coding
Range Updating
rate
R 03/04
W 16
137 1 D-value R/W*
EEPROM
U16
Seconds 0...1000 s Slow
03/04 400 16 Lockout history (current lockout) R U16/U32 [] Fast
03/04 416 16 Lockout history (current lockout -1) R U16/U32 [] Fast
03/04 432 16 Lockout history (current lockout -2) R U16/U32 [] Fast
: : : : : :
03/04 528 16 Lockout history (current lockout -8) R U16/U32 [] Fast
03/04 544 8 Error history (current error) R U16/U32 [] Fast
03/04 552 8 Error history (current error -1) R U16/U32 [] Fast
: : : : : :
03/04 704 8 Error history (current error -20) R U16/U32 [] Fast
* These parameters do not need to be continually written since they are stored in EEPROM, which only permits a limited
number of write accesses over its lifecycle (< 100,000).
Data structures
Date
U16
1:
Year
2: Month
3: Day
Time of day
U16
1:
Hour
2: Minute
3: Second
Lockout history
U16
1:
Error code
2: Error diagnostics
3: Error class
4: Error phase
5: Fuel
6: Output
7: Da
te - Year
8: Date - Month
9: Date - Day
10: Time of day - Hours
11: Time of day - Minutes
12: Time of day - Seconds
U32
13, 14:
Startup counter total
15, 16: Hours run total
Error history
U16
1:
Error code
2: Error diagnostics
3: Error class
4: Error phase
5: Fuel
6: Output
U32
7, 8:
Startup counter total
