Section 8 Page 10 SCC Inc.
Legend to address table
Access
R
Value can only be read
R / W
Value can be read and written
Data format
S16
U16
16 bit integer, subject to sign
16 bit integer, not subject to sign
S32
32 bit integer, subject to sign
Note:
In the AZL..., this data type is also
used to mark an in
valid or non-
available value by using the value
of «-1»
[ ]
Data array
* These parameters do not need to be
continually written since they are stored in EEPROM,
which only permits a limited number of write accesses over its lifecycle (< 100,000).
Data types
TYPE Phys. Int. range Resolution Conversion int. / phys.
Percent 0...100 % 0...1000 0.1 % / 10
Percent 0...110 % 0...1100 0.1 % / 10
Degrees -3.0...93.0° -30...930 0.1° / 10
Process units 0...2000°
32...3632 °F
0...100 bar
0...1449 psi
0...2000
32...3632
0...1000
0...1449
1 °C
1 °F
0.1 bar
1 psi
1
1
/ 10
1
Fire rate Modulating
operation: 0...100 %
Multistage operation:
1001 = stage 1
1002 = stage 2
1003 = stage 3
0...1003 Modulating
operation:
0.1 %
Multistage
operation:
1
Modulating operation:
/ 10
Multistage operation:
- 1000
Adaption list
0: Undefined
1: Identification completed, parameter determined
2: Undefined
3: Adaption aborted by user
4: Temperature differential too small, temperature will
be lowered with low-fire
5: Monitoring time running
6: Delivery of identification load set
7: Error during identification (path)
8: Error during identification (internally)
9: Monitoring time running
10: Changeover from modulating to multistage during an identification
11: Timeout monitoring time
12: Timeout heating output on path with monitoring
