Siemens LMV5 Series Technical Instructions

LMV Series Technical Instructions
Document No. LV5-10
00
SCC Inc. Page 11 Section 8
Modbus Address / LMV5 Parameter Cross-Reference Guide
Modbus
Address
Description LMV5 Parameter
Modbus
Address
Description LMV5 Parameter
0
Phase
56, 57
Hours run on gas
GasFiring
1
Position of active fuel actuator
58, 59
Hours run on oil stage 1
OilStage1/Mod
2
Position of gas actuator
60, 61
Hours run on oil stage 2
OilStage2
3
Position of oil actuator
62, 63
Hours run on oil stage 3
OilStage3
4
Position of air actuator
64, 65
Total hours run (resettable)
TotalHoursReset
5
Position of aux 1 actuator
66, 67
Total hours run (not resettable)
TotalHours
6
Position of aux 2 actuator
68, 69
Total hours system has been powered
SystemOnPower
7
Position of aux 3 actuator
70, 71
Startup counter gas
GasStartCount
8
Position of VSD
72, 73
Startup counter oil
OilStartCount
9
Current fuel
74, 75
Startup counter total (resettable)
TotalStartCountR
10
Current output
76, 77
Startup counter total (not resettable)
TotalStartCount
11
Current setpoint
78, 79
Total volume of gas
Volume Gas
12
Actual value
80, 81
Total volume of oil
Volume Oil
13
Flame signal
FlameSig QRI_B
82
Total number of lockouts
LockoutCounter
14
Current fuel throughput
Curr Flow Rate
83
Additional sensor: current temperature
Temp. ColdStart
15
Current O2 value
Current O2 Value
84-91
AZL5 ASN
ASN
16
Gas volume unit
PulseValueGas
92
AZL5 parameter set code
ParamSet Code
17
Oil volume unit
PulseValueOil
93
AZL5 parameter set version
ParamSet Vers
18
Unit of temperature
PhysicalUnits
94-96
AZL5 identification date
ProductionDate
19
Unit of pressure
PhysicalUnits
97
AZL5 identification number
SerialNumber
20
Sensor type
Sensor Select
98-105
LMV5 ASN
ASN
21, 22
Startup counter total
TotalStartCount
106
LMV5 parameter set code
ParamSet Code
23, 24
Hours run total
TotalHours
107
LMV5 parameter set version
ParamSet Vers
25
Current error: code
108-110
LMV5 identification date
ProductionDate
26
Current error: diagnostic
111
LMV5 identification number
SerialNumber
27
Current error: class
112
AZL5 software version
SW Version
28
Current error: phase
113
LMV5 software version
SW Version
29
Temperature limiter off threshold
TL_ThreshOff
114
Load c ontroller software version
SW Version
30
Supply air temperature
SupplyAirTemp
115-122
Burner ID
BurnerID
31
Flue gas temperature
FlueGasTemp
123
Minimum allowed load on gas
MinLoadGas
32
Combustion efficiency
CombEfficiency
124
Maximum allowed load on gas
MaxLoadGas
35
Inputs (bits)
N/A
125
Minimum allowed load on oil
MinLoadOil
37
Outputs (bits)
N/A
126
Maximum allowed load on oil
MaxLoadOil
38
Program stop
ProgramStop
127
Load limitation end user, modulating
User MaxLoadMod
39
Load controller operating mode
LC_OptgMode
128
Load limitation end user, multi-stage
User MaxLoadStg
40
Manual / automatic operation
Autom/Manual/Off
129
Temperature limiter ON differential
TL_SD_On
41
Modbus mode: local / remote
Local / Remote
130
Measuring range for temperature sensors
MeasureRangePtNi
42
Modbus downtime
Timeout
131
Adaption active / inactive
StartAdaption
43
Modbus: operating mode in remote
Remote Mode
132
Adaption state
StartAdaption
44
External setpoint W3
W3
133
Start adaption
StartAdaption
45
Predefined output
SetLoad
134
Adaption output
AdaptionLoad
46
AZL fuel selection
CurrentFuel
135
PID proprtional band value
P-Part
47
Setpoint W1
SetpointW1
136
PID integral value
I-Part
48
Setpoint W2
SetpointW2
137
PID derivative value
D-Part
49
Weekday
Weekday
400-543
Lockout history
LockoutHistory
50-52
Date
Date
544-711
Fault history
FaultHistory
53-55
Time of day
TimeOfDay
See "Status/Reset"
screen
See "Normal
Operation" screen
HOME
