Change password
1. The "Network Trace" window is open.
2. Press the "Change password" softkey.
The "Change Password" window opens.
Enter a new password and confirm with "OK".
Trace parameters
You can parameterize the conditions for the log recording via the "Parameters (tcpdump)" input
field in the Network Trace window.
Syntax
<switch> <option>
<switch> parameters
Value Meaning
-D Displays a list of all network interfaces. All other <Switch> parameters
are ignored.
-i <interface> Defines which network interface has to be checked.
-n Host names are not resolved.
-c <number> The recording is stopped after a defined number of packets.
-C <file size> Limits the file size. When the file size is reached, a new file with name
and consecutive number, starting with 1, is created. The unit of the file
size corresponds to million bytes.
-e Outputs the Ethernet header.
-q Creates an abbreviated log version.
-vv Creates more detailed packet information.
-S Changes the packet sequence number from absolute to relative.
-A Outputs the contents of a packet as ASCII.
-xx Outputs the contents of a packet as Hex.
-XX Outputs the contents of a packet as Hex and as ASCII.
-s <bytes> Specifies the packet size in bytes that has to be recorded per packet.
The default is 68 bytes.
Note
The value -w is always implicitly contained in the call for the creation of the standard log file:
HMI data/Logs/Network trace/tcpdump.pcap or windump.pcap
Configuring the network
17.6 Station-related network diagnostics
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 399
