[1] = 3 Rotary axis (main spindle) C1
[2] = 2 Parallel to the rotary axis ZC
MD24320 $MC_TRAFO_GEOAX_ASSIGN_TAB_3[ ] Assignment of geometry axes to channel
axes for transformation 3.
[0] = 1 1st channel axis X
[1] = 3 2nd channel axis Y
[2] = 2 3rd channel axis Z
MD24800 $MC_TRACYL_ROT_AX_OFFSET_1 Offset of the rotary axis for the 1st TRACYL
transformation.
= 0
MD24805 $MC_TRACYL_ROT_AX_FRAME_1 Axial offset of the rotary axis is taken into
account during TRACYL.
= 2
MD24810 $MC_TRACYL_ROT_SIGN_IS_PLUS_1 Sign of the rotary axis for the 1st TRACYL
transformation.
= 1
MD24820 $MC_TRACYL_BASE_TOOL_1[ ] Vector of the base tool for the 1st TRACYL
transformation.
[0] = 0
[1] = 0
[2] = 0
Setting up cylinder surface transformation under ShopTurn
In addition, set the following channel-specific configuration machine data:
MD52214 $MCS_FUNCTION_MASK_MILL Milling function screens
Bit 3 Enable "internal / rear" machining in ShopTurn screens that define the machining plane
themselves.
Bit 4 If you have implemented the "Clamp/release spindle" function using the machine manu‐
facturer cycle CUST_TECHCYC.SPF, then using this machine data, you can activate the
"Clamp/release spindle" parameter in the drilling and milling screens.
= 0 The "Clamp/release spindle" parameter is not displayed in the drilling and milling screens.
ShopTurn automatically clamps the spindle if it makes sense for the particular machining
operation.
= 1 The "Clamp/release spindle" parameter is displayed in the drilling and milling screens.
The operator decides for which machining operation the spindle should be clamped.
Technologies and cycles
21.5 Turning
SINUMERIK Operate (IM9)
546 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
