Cylinder surface transformation with groove side offset
MD24300 $MC_TRAFO_TYPE_3 Definition of the 3rd transformation in the
channel.
= 513 TRACYL main spindle
MD24310 $MC_TRAFO_AXES_IN_3[ ] Axis assignment for transformation 3.
[0] = 1 Perpendicular to the rotary axis XC
[1] = 3 Rotary axis (main spindle) C1
[2] = 2 Parallel to the rotary axis ZC
[3] = 6 Parallel to the cylinder surface and perpendicular to the rotary axis ZC
MD24320 $MC_TRAFO_GEOAX_ASSIGN_TAB_3[ ] Assignment of geometry axes to channel
axes for transformation 3.
[0] = 1 1st channel axis X
[1] = 3 2nd channel axis Y
[2] = 2 3rd channel axis Z
MD24800 $MC_TRACYL_ROT_AX_OFFSET_1 Offset of the rotary axis for the 1st TRACYL
transformation.
= 0
MD24805 $MC_TRACYL_ROT_AX_FRAME_1 Axial offset of the rotary axis is taken into
account during TRACYL.
= 2
MD24810 $MC_TRACYL_ROT_SIGN_IS_PLUS_1 Sign of the rotary axis for the 1st TRACYL
transformation.
= 1
MD24820 $MC_TRACYL_BASE_TOOL_1[ ] Vector of the base tool for the 1st TRACYL
transformation.
[0] = 0
[1] = 0
[2] = 0
Technologies and cycles
21.5 Turning
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 547
