Dimension drawings
12.1 Dimension drawings of the 3KC4 transfer switching equipment
Manual, 08/2017, L1V30368969104A-02
193
mm
250 A
400 A
630 A
3P
4P
3P
4P
3P
4P
A 264.6 264.6 264.6 264.6 341.1 341.1
B 244 244 244 244 321 321
C 288 288 288 288 402 402
D 328 378 328 378 377 437
E 152 152 152 152 221 221
F 195 245 195 245 244 304
G 35 35 35 35 34 34
H 160 210 160 210 210 270
I 50 50 50 50 65 65
J 25 25 35 35 45 45
K 30 30 35 35 50 50
L 11 11 11 11 13 13
M 33 33 33 33 42.5 37.5
N 3.5 3.5 3.5 3.5 5 5
O 39.5 39.5 39.5 39.5 53 53
P 133.5 133.5 133.5 133.5 190 190
Q 160 160 170 170 260 260
R 130 130 140 140 220 220
S 15 15 15 15 29 20
