Dimension drawings
12.1 Dimension drawings of the 3KC4 transfer switching equipment
Manual, 08/2017, L1V30368969104A-02
195
mm
800 A
1000 A
1250 A
1600 A
3P
4P
3P
4P
3P
4P
3P
4P
A 370 370 370 370 370 370 380 380
B 461 461 461 461 461 461 531 531
C 504 584 504 584 504 584 596 716
D 307 387 307 387 307 387 399 519
E 255 335 255 335 255 335 347 467
F 80 80 80 80 80 80 120 120
G 50 50 50 50 60 60 90 90
H 60.5 60.5 60.5 60.5 65 65 44 44
I 47.5 47.5 47.5 47.5 47.5 47.5 53 53
J 7 7 7 7 7 7 8 8
K 66.5 66.5 66.5 66.5 66.5 66.5 67.5 67.5
L 321 321 321 321 330 330 288 288
