Connection
6.3 Connecting the control circuit
Manual, 08/2017, L1V30368969104A-02
93
The following figure shows a 3KC9830-, 3KC9831- power supply kit for 4-pole applications
with neutral.
Figure 6-80 3KC9830-, 3KC9831- power supply kit for 4-pole applications (3KC9831- for fastening on
top of the transfer switching equipment is shown here)
