Parameter Default Setting Setting Range
H1
H2
Only the indications for the
parameterization of the binary
outputs are displayed which
can be used according to the
current device settings.
-none- Acc. to list box
Limit violation and Group Indication
Designation can be changed during the parame-
terization.
Indication inverted No No
Yes
Automation Functions
Limit Violation 1-8 and 9-16
Table 13-14 Settings for Limits
Parameter Default Setting Setting Range
Measurement -none- Measured value selection list depending on
network type
Limit
0.00
25
-1 000 000 000.00 to 1 000 000 000.00 (unit)
Limit type Lower Lower
Upper
Hysteresis (%) 1.00 0.00 to 10.00
Violation indication Limit Violation x
(x = 1 to 16)
The name of the indication is customizable;
max. 31 characters.
Group Indications 1-4
Table 13-15
Settings for Group Indications
Parameter Default Setting Setting Range
Source
Only the indications for the
parameterization of the binary
outputs are displayed which
can be used according to the
current device settings.
-none- Acc. to list box
Limit violation and group indication:
Designation can be changed during the parame-
terization.
Source inverted No No
Yes
Logic operation NONE NONE
OR
AND
Group indication name Group Indication x
(x = 1 to 4)
The name of the indication is customizable;
max. 31 characters.
13.3.2
13.3.2.1
13.3.2.2
25
The limit value must be the primary value.
Operational Indications and Operating Parameters
13.3 Advanced Functions
270 SICAM, SICAM P850/P855 7KG85X, Manual
E50417-H1040-C482-A9, Edition 03.2022

Siemens SICAM 7KG85X Specifications

General

Frequency	50/60 Hz
Binary inputs	8
Binary outputs	4
Frequency Range	45 - 65 Hz
Communication Interface	Ethernet, RS485
Protection Class	IP20
Protocols	IEC 61850, DNP3, Modbus
Measurement Category	CAT III
Current Input	5A
