Parameter Default Setting Setting Range
Tolerance unit Percentage Percentage
Numerical
Upper threshold 110.00 % of nominal current 5.0 % to 200.0 % of the nominal
current
Lower threshold 90.00 % of nominal current 0.00 % to 99.99 % of the nominal
current
Hysteresis 2.00 % of the nominal current 0.0 % to 50.0 % of the nominal current
Waveform capture setting
Total recording duration 2.0 s 0.2 s to 3.0 s, increments of 0.2 s
Pretrigger ratio 10% 0 % to 30 %, increments of 5 %
Records Parameters (only SICAM P855)
Table 13-22 Settings for Measurement Records (only SICAM P855)
Parameter Default Setting Setting Range
Average intervals - Frequency 10 s fixed
Short term flicker 10 min fixed
Long term flicker 2 h fixed
Average interval - Voltage /
Unbalance / THDS / Harmonics
10 min 1 min
10 min
Record additional data (I, P, Q,
S etc.)
no no
yes
Recorder of average - Min no no
yes
Recorder of average - Max no no
yes
Harmonics Odd Even
Odd
All
File generation every:
(corresponds to the setting of
the Average interval parameter)
The created PQDIF files can be
downloaded via the Web pages
or the IEC 61850 protocol.
24 h At average interval: File generation every:
1 min 2 h (fixed)
10 min 2 h
24 h
Trend Records (only SICAM P855)
Table 13-23
Settings for Trend Records (only SICAM P855)
Parameter Default Setting Setting Range
Tolerance unit Percentage Percentage
Numerical
Tolerance number Percentage: 3 % of the primary nominal
voltage
Numerical: 0.5 V
1 % to 5 %, increments of 1 %
0.2 V to 500.0 V
Maximum recording
interval
2 h 2 h
24 h
13.3.5.3
13.3.5.4
Operational Indications and Operating Parameters
13.3 Advanced Functions
274 SICAM, SICAM P850/P855 7KG85X, Manual
E50417-H1040-C482-A9, Edition 03.2022
