Siemens SIMATIC IPC347G

BIOS description
11.3 Advanced menu
SIMATIC IPC347G
Operating Instructions, 10/2020, A5E50059993-AA
87
CPU Configuration
In the CPU configuration page, you can check and configure the CPU-related information that
the BIOS automatically detect.
System
parameters
Function description Configuration
options
Default setting
Intel
(VMX)Virtuali
zation Tech-
nology
Enable or disable the intel virtualization technology.
• [Enabled]: A VMM can utilize the additional hardware capabili-
ties provided by Vanderpool Technology.
• [Disabled]: Disable this function.
• [Enabled]
• [Disabled]
[Enabled]
Turbo Mode
Enable or disable the processor Turbo Mode.
• [Enabled]
•
[Disabled]
[Enabled]
Active Pro-
cessor Cores
Select the number of CPU cores to activate in each processor pack-
age.
Note: Some of the CPU types only have [All] and [1] options.
• [All]
• [1]
• [2]
• [3]
[All]
EIST
Enable or disable Enhanced Intel SpeedStep® Technology.
• [Enabled]
• [Disabled]
[Enabled]
Reserve for
OS memory
Select the reserve value for operating system memory.
• [Dynamic]
• [3 GB]
[Dynamic]
Chipset Configuration
In the Chipset Configuration page, you can change the platform settings.
System
parameters
Function description Configuration
options
Default setting
Primary Dis-
play
1
Select the Primary Display from IGFX/PEG/PCI Graphics device or
select SG for switchable Gfx.
• [Auto]
• [CPU Graphics]
•
[PCIE]
[CPU Graphics]
iGPU Multi-
Monitor
Enable or disable the iGPU Multi-Monitor.
• [Enabled]: To empower both integrated and discrete graphics.
The iGPU shared system memory size will be fixed at 64MB.
• [Disabled]: Disable this function.
• [Enabled]
• [Disabled]
[Disabled]
IGD Mini-
mum
Memory
Select DVMT 5.0 Pre_Allocated (Fixed) Graphics Memory size used
by the Internal Graphics Device.
• [32M] [64M]
[96M] ~
[1024M]
[128M]
Audio Con-
troller
Enable or disable the Azalia HD audio controller.
• [Enabled]
• [Disabled]
[Enabled]
