Siemens SIMATIC IPC347G

BIOS description
11.3 Advanced menu
SIMATIC IPC347G
88 Operating Instructions, 10/2020, A5E50059993-AA
System
parameters
Function description Configuration
options
Default setting
Audio Detect
Enable or disable the audio device detection function.
• [Enabled]
•
[Disabled]
[Enabled]
High Preci-
sion Timer
Enable or disable the High Precision Event Timer.
• [Enabled]
• [Disabled]
[Enabled]
1
Refer to the following table to select the correct configuration options for Primary Display when you connect external
graphic cards.
System parameters
BIOS
Power On process
Windows operating system
iGPU
Multi-
Monitor
Primary
Display
I-VGA
I-DP
PEG
I-VGA
I-DP
PEG
I-VGA
I-DP
PEG
[Enabled]
[Auto]
×
×
✓
×
×
✓
✓
✓
✓
[CPU
Graphics]
✓
✓
×
✓
✓
×
✓
✓
✓
[PEG]
×
×
✓
×
×
✓
✓
✓
✓
[Disa-
bled]
[Auto]
×
×
✓
×
×
✓
×
×
✓
[CPU
Graphics]
✓
✓
×
✓
✓
×
✓
✓
✓
[PEG]
×
×
✓
×
×
✓
×
×
✓
SATA Configuration
When you enter the BIOS Setup, the BIOS automatically detects the presence of SATA devices.
If no SATA device is installed to the corresponding SATA port, the SATA Port items show
Empty.
System
parameters
Function description Configuration
options
Default setting
SATA6G_1
Enable or disable the SATA port SATA6G_1.
• [Enabled]
•
[Disabled]
[Enabled]
SATA6G_1
Hot Plug
Enable or disable the SATA6G_1 Hot Plug Support.
• [Enabled]
• [Disabled]
[Disabled]
SATA6G_2
Enable or disable the SATA ports SATA6G_2.
• [Enabled]
•
[Disabled]
[Enabled]
SATA6G_2
Hot Plug
Enable or disable the SATA6G_2 Hot Plug Support.
• [Enabled]
• [Disabled]
[Disabled]
SATA6G_3
Enable or disable the SATA port SATA6G_3.
• [Enabled]
•
[Disabled]
[Enabled]
SATA6G_3
Hot Plug
Enable or disable the SATA6G_3 Hot Plug Support.
• [Enabled]
• [Disabled]
[Disabled]
