Siemens SIMATIC IPC347G User Manual

BIOS description
11.3 Advanced menu
SIMATIC IPC347G
92 Operating Instructions, 10/2020, A5E50059993-AA
System parameters Function description Configuration
options
Default setting
INTEL LAN2_X2P1
PXE OPROM
Enable or disable the INTEL LAN2_X2P1 PXE OPROM.
• [Enabled]
•
[Disabled]
[Enabled]
Add-on PCIE LAN
Card PXE Boot
Enable or disable the Add-on PCIE LAN Card PXE Boot.
• [Enabled]
• [Disabled]
[Disabled]
Charging USB device
in Power State S5
Enable or disable the charging USB devices even when the
system is in Power State S5.
• [Enabled]
•
[Disabled]
[Enabled]
Network Stack Configuration
In the Network Stack Configuration page, you can configure network stack.
System parameters Function description Configuration
options
Default setting
Network Stack
Enable or disable the UEFI Network Stack.
• [Enabled]
• [Disabled]
[Enabled]
Ipv4 PXE Support
Enable or disable the Ipv4 PXE Boot support.
• [Enabled]
•
[Disabled]
[Enabled]
Ipv6 PXE Support
Enable or disable the Ipv6 PXE Boot support.
• [Enabled]
• [Disabled]
[Enabled]
PCIE Configuration
In the PCIE Configuration page, you can configure the onboard devices.
System parameters Function description Configuration
options
Default setting
PCIEX16
Enable or disable the PCIEX16.
• [Enabled]
•
[Disabled]
[Enabled]
PCIEX16 Speed
Configure PCIEX16 Gen1-Gen3.
• [Auto]
• [Gen1]
• [Gen2]
• [Gen3]
[Auto]
PCIEX16 Non-Compliance
mode
Detect Non-Compliance PCI Express Device in PCIEX16.
• [Enabled]
•
[Disabled]
[Disabled]
PCIEX4 Lane Configuration
Set the PCIEX4 Lane.
• 1×2 2×1 Port
• 1×4 Port
[1×2 2×1 Port]
PCIEX4_1
Enable or disable the PCIEX4_1.
• [Enabled]
•
[Disabled]
[Enabled]
