Siemens SIMATIC IPC347G

BIOS description
11.3 Advanced menu
SIMATIC IPC347G
Operating Instructions, 10/2020, A5E50059993-AA
91
System parameters Function description Configuration options Default set-
ting
Serial Port 3
Configuration
Serial Port 3
Enable or disable the serial port (COM) 3.
• [Enabled]
•
[Disabled]
[Enabled]
Change Set-
tings
When you set the Serial Port 3 to [Ena-
bled], this item allows you to select the
Serial Port base address.
• [Auto]
• [IO=2F0h; IRQ=7]
• [IO=3E8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=2E8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=2F0h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=2E0h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
[Auto]
Serial Port 4
Configuration
Serial Port 4
Enable or disable the serial port (COM) 4.
• [Enabled]
•
[Disabled]
[Enabled]
Change Set-
tings
When you set the Serial Port 4 to [Ena-
bled] and allows you to select the Serial
Port base address.
• [Auto]
• [IO=2E0h; IRQ=7]
• [IO=3E8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=2E8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=2F0h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=2E0h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
[Auto]
M.2 Detect Information
This page displays the information of the connected M.2 devices.
Onboard Device Configuration
In the Onboard Device Configuration page, you can configure the onboard devices.
System parameters Function description Configuration
options
Default setting
INTEL LAN1_X1P1
Controller
Enable or disable the INTEL LAN_X1P1 Controller.
• [Enabled]
•
[Disabled]
[Enabled]
INTEL LAN1_X1P1
PXE OPROM
Enable or disable the INTEL LAN1_X1P1 PXE OPROM.
• [Enabled]
• [Disabled]
[Enabled]
INTEL LAN2_X2P1
Controller
Enable or disable the INTEL LAN2_X2P1 Controller.
• [Enabled]
•
[Disabled]
[Enabled]
