Siemens SIMATIC IPC347G

BIOS description
11.3 Advanced menu
SIMATIC IPC347G
90 Operating Instructions, 10/2020, A5E50059993-AA
Serial Port Configuration
In the Serial Port Configuration page, you can set the serial port configuration.
System parameters Function description Configuration options Default set-
ting
Serial Port 1
Configuration
Serial Port 1
Enable or disable the serial port (COM) 1.
• [Enabled]
•
[Disabled]
[Enabled]
Change Set-
tings
When you set the Serial Port 1 to [Ena-
bled], this item allows you to select the
Serial Port base address.
• [Auto]
• [IO=3F8h; IRQ=4]
• [IO=3F8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=2F8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=3E8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=2E8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
[Auto]
COM1 Control
When you set the Serial Port 1 to [Ena-
bled], this item allows you to select the
COM1 mode.
• [RS232]
• [RS422]
•
[RS485]
[RS232]
Serial Port 2
Configuration
Serial Port 2
Enable or disable the serial port (COM) 2.
• [Enabled]
• [Disabled]
[Enabled]
Change Set-
tings
When you set the Serial Port 2 to [Ena-
bled], this item allows you to select the
Serial Port base address.
• [Auto]
• [IO=2F8h; IRQ=3]
• [IO=3F8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=2F8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=3E8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
• [IO=2E8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12;]
[Auto]
COM2 Control
When you set the Serial Port 2 to [Ena-
bled], this item allows you to select the
COM2 mode.
• [RS232]
• [RS422]
• [RS485]
[RS232]
