Technical specifications
9.3 Technical specifications
KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
107
9.3 Technical specifications
Weight
KP8, including connector and mounting clamps,
without packaging
270 g
KP8F, including connector and mounting clamps,
without packaging
280 g
KP32F, including connector and mounting clamps,
without packaging
1,220 g
Power supply
Physical variable KP8, KP8F KP32F
Nominal value +24 VDC
Voltage range, permitted +20.4 V to +28.8 V (–15 %, +20 %)
Current consumption, without load ≤ 0.3 A ≤ 1.0 A
Electrical isolation No
Short-circuit protection Yes
Transients, maximum permissible 35 V, 500 ms
Time between two transients ≥ 50 s
Fuse, internal 4 A
Sensor
Physical variable KP8, KP8F KP32F
Signal duration ≥ 50 ms
KP8 and KP32F in non fail-safe operation - digital inputs/outputs
Physical variable KP8, KP8F KP32F
Connectable Keys, switches
Number of digital inputs, standard mode 0 16
Number of digital inputs/outputs, standard
mode
8 16
Electrically isolated from internal logic No
Cable length
• Unshielded cable
• Shielded cable
≤ 3 m
≤ 10 m
Input current with "1" signal and 24 V 5 mA, typical
Delay in the digital inputs/outputs 0.3 ms
Bounce time ≤ 10 ms
