Technical specifications
9.5 Interface description
KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
115
Pin number Pin Assignment
1 I0.16 digital input/output 16
2 I0.17 digital input/output 17
… … …
15 I0.30 digital input/output 30
16 I0.31 digital input/output 31
17 FI.0 Fail-safe digital input 0
18 VS.0 Sensor supply 0 for FI.0
19 FI.1 Fail-safe digital input 1
20 VS.1 Sensor supply 1 for FI.1
21 FI.2 Fail-safe digital input 2
22 VS.2 Sensor supply 2 for FI.2
23 FI.3 Fail-safe digital input 3
24 VS.3 Sensor supply 3 for FI.3
9.5.4 PROFINET
X1, RJ45 socket, 8-pin
Pin number Pin Assignment
1 RxP Receive data +
2 RxN Receive data –
3 TxP Transmit data +
4 GND n. c.
5 GND n. c.
6 TxN Transmit data –
7 GND n. c.
8 GND n. c.
