KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
3
Preface
Purpose of the operating instructions
This operating manual provides information for manuals derived from the requirements for
mechanical engineering documentation according to DIN EN 62079. This information relates
to the place of use, transport, storage, mounting, use and maintenance.
These operating instructions are intended for:
● Project planning engineers
● Users
● Commissioning engineers
● Maintenance personnel
Pay particular attention to the chapter "Safety Instructions (Page 23)".
Required knowledge
General knowledge of automation technology and process communication is needed to
understand the operating instructions.
It is also assumed that those using the manual have experience in using personal computers
and an understanding of Microsoft operating systems.
You must have knowledge about the STEP 7 software and about safety-related technology.
Scope
The operating instructions applies to the following HMI devices:
● KP8, order number 6AV3688-3AY36-0AX0
● KP8F, order number 6AV3688-3AF37-0AX0
● KP32F, order number 6AV3688-3EH47-0AX0
Note
The manual is part of the HMI device and will be required for repeat commissioning.
Retain all enclosed and additional documents for the entire service life of the HMI device.
You must pass on all these documents to future owners of the HMI device.
