Siemens SIMATIC KP8 User Manual

Mounting and connecting the HMI device
4.4 Connecting the HMI device
KP8, KP8F, KP32F
52 Operating Instructions, 11/2011, A5E03284305-02
4.4.4 Connecting the power supply
Configuration diagram
The figure below shows the connection between KP8 or KP8F and the power supply.
00
/ /
00
/ /
.3
.3)
The figure below shows the connection between KP32F and the power supply.
The interfaces are described in the section "Interface description (Page 112)".
