1.5 Accessory kit
KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
17
1.5 Accessory kit
Device Content of the accessory kit
KP8
• A 12-pin plug connector
• Four mounting clamps for mounting the HMI device
KP8F
• A 16-pin plug connector
• Four mounting clamps for mounting the HMI device
KP32F
• One mains terminal
• A 16-pin plug connector
• A 24-pin plug connector
• 10 mounting clamps for mounting the HMI device
The accessory kit can include documents.
1.6 Service packages
KP8
This service pack contains:
1 set connector, 12-pin, order number 6AV6671-3XY39-4AX0
KP8F, KP32F
This service pack contains:
1 set connector, 16-pin, order number 6AV6671-3XY49-4AX0
KP8, KP8F, KP32F
This service pack contains:
1 set plastic mounting clamps, order number 6AV6671-8XK00-0AX2
KP32F
The service packs contain:
● 1 connector, 24-pin, order number 6AV6671-3XY58-4AX0
● 2 mains supply terminals, 2-pin, order number 6ES7193-4JB00-0AA0
