Assigning parameters for the HMI device in STEP 7
6.4 KP32F
KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
89
8. Check the standard entry of the addresses.
Change the entries, if required.
9. Click "OK".
The entries are saved. The dialog box closes.
Result
The switch states of the digital inputs/outputs of the HMI device are stored in the specified
address area of the controller.
6.4.6 Setting the fail-safe properties
This step applies to the fail-safe slot 5.
You can delete slot 5 in the detailed view in HW Config. If slot 5 has been deleted, you can
operate the KP32F in non fail-safe operation.
Requirement
● You know the password for the safety program.
● A project is open in "HW Config".
Procedure
1. Double click in the properties window on slot 5.
The "Properties – F-DI" dialog box is displayed.
2. Select the "General" tab.
Parameter Meaning
Name The name is displayed in the detail view, "Module" column
Comment The name is displayed in the detail view, "Comment" column
3. Change the entries, if required.
