KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
33
Planning the use
3
3.1 "Plan use" check list
Before deploying the HMI device, you should check that the planned operation of the HMI
device complies with the following test steps.
Test step Information Check
Check climatic and mechanical ambient
conditions
Ambient conditions for storage and
transport (Page 33)
Set mounting position, installation location and
mounting type of the HMI device
Mounting Positions and Type of Fixation
(Page 37)
Prepare installation cut-out Preparing for Mounting (Page 38)
Check insulation voltage, protection class and
seal tightness
Insulation resistance, protection class and
degree of protection (Page 41)
Select sensors for fail-safe operation Requirements for fail-safe operation
(Page 42)
Check compliance with the technical data Technical specifications (Page 107)
3.2 Ambient conditions for storage and transport
The shipping conditions of this HMI device exceed requirements in accordance with
IEC 61131-2. The following specifications apply to devices that are shipped and stored in the
original packaging.
The climatic ambient conditions conform to the following standards:
● IEC 60721-3-3:1994, Class 3K7 for storage
● IEC 60721-3-2:1997, Class 2K4 for transportation
The mechanical ambient conditions are compliant with IEC 60721-3-2:1997, Class 2M2.
