Planning the use
3.2 Ambient conditions for storage and transport
KP8, KP8F, KP32F
34 Operating Instructions, 11/2011, A5E03284305-02
In the following table, the tests are contained that were checked on the HMI device in
regards to the ambient conditions for transport and storage.
Test Permitted range
Drop test, in transport package ≤ 1 m
Temperature –20 to +60 °C
Air pressure
acc. to IEC 60068-2-13:1983
1080 to 660 hPa,
corresponds to an elevation of -1000 to 3500 m
Humidity, relative 10 to 95 %, without condensation
Vibration, sinusoidal as per
IEC 60068-2-6:2007
Test Fc
• 5 to 8 Hz, 3.5 mm, 10 cycles per axis
• 8 to 500 Hz, 9.8 m/s
2
, 10 cycles per axis
Shock
as per IEC 60068-2-27:2008
Test Ea
250 m/s
2
, 6 ms, 1000 shocks
NOTICE
Equipment failure
Moisture and condensation lead to malfunction. Moisture in the form of condensation on or
in the device is formed:
• When transporting a device at low temperatures
• Under extreme temperature variations
Bring the device to room temperature before operating.
Condensation
When condensation is on the device, do not expose the HMI device to direct radiation from
a heater.
If condensation has developed, wait approximately 4 hours until the HMI device has dried
completely before switching it on.
The following points must be adhered to in order to ensure a fault-free and safe operation of
the HMI device:
● Proper transportation and storage
● Proper installation and mounting
● Careful operation and maintenance
The warranty for the HMI device will be deemed void if these stipulations are not heeded.
