Overview
1.4 Structure of the KP32F
KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
15
1.4 Structure of the KP32F
Front view and side view
① Oblong holes for a mounting clamp
② Keyboard
