Overview
1.3 Design of KP8 and KP8F
KP8, KP8F, KP32F
14 Operating Instructions, 11/2011, A5E03284305-02
Rear view KP8F
① Power supply connection and digital inputs and outputs
② Bar for strain relief
③ DIP switch
④ Seal
⑤ PROFINET interfaces
