Assigning parameters for the HMI device in STEP 7
6.4 KP32F
KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
87
Result
The switch states of the digital inputs/outputs of the HMI device are stored in the specified
address area of the controller.
6.4.4 Setting the properties of the digital inputs
Requirement
● A project is open in "HW Config".
Procedure
1. Double-click slot 3 in the detailed view.
The dialog box "Properties – 16 DI DC24V" is displayed.
2. Select the "General" tab.
Parameter Meaning
Name The name is displayed in the detail view, "Module" column
Comment The name is displayed in the detail view, "Comment" column
3. Change the entries, if required.
4. Open the "Addresses" tab.
In the "Inputs" group, the start value of the address range is set depending on the
controller used. The signals of the HMI device are mapped in these address ranges.
Parameter Meaning
Inputs > Start Start of the address range in which the user data of the HMI device
are mapped.
Inputs > Process Image Process image to which the address range belongs.
This parameter cannot be entered with a controller of the
SIMATIC CPU 300 type.
5. Check the standard entry of the addresses.
Change the entries, if required.
6. Click "OK".
The entries are saved. The dialog box closes.
Result
The switch states of the digital inputs of the HMI device are stored in the specified address
area of the controller.
