Assigning parameters for the HMI device in STEP 7
6.4 KP32F
KP8, KP8F, KP32F
86 Operating Instructions, 11/2011, A5E03284305-02
Procedure
1. Double-click slot 1 in the detailed view.
The dialog box "Properties – 16 keys/LEDs" is displayed.
2. Select the "General" tab.
Parameter Meaning
Name The name is displayed in the detail view, "Module" column
Comment The name is displayed in the detail view, "Comment" column
3. Change the entries, if required.
4. Open the "Addresses" tab.
In the "Inputs" and "Outputs" groups, the start values of the address areas are set
depending on the controller used. The signals of the HMI device are mapped in these
address ranges.
Parameter Meaning
Inputs > Start Start of the address range in which the user data of the HMI device
are mapped.
Inputs > Process Image Process image to which the address range belongs.
This parameter cannot be entered with a controller of the
SIMATIC CPU 300 type.
Outputs > Start Start of the address range in which the user data of the HMI device
are mapped.
Outputs > Process Image Process image to which the address range belongs.
This parameter cannot be entered with a controller of the
SIMATIC CPU 300 type.
5. Check the standard entry of the addresses.
Change the entries, if required.
6. Select the "Parameters" tab.
7. Open the "Parameters > Device-specific parameters" folder.
Parameter Meaning
Duration of the light test The value range from 0 to 60 s can be set.
With the value "0", no light test is executed.
Default setting is 5 s.
Brightness Adjustable:
very bright, bright, normal, dark or very dark
Default setting is "normal".
8. Change the entries, if required.
9. Click "OK".
The entries are saved. The dialog box closes.
