Mounting and connecting the HMI device
4.4 Connecting the HMI device
KP8, KP8F, KP32F
48 Operating Instructions, 11/2011, A5E03284305-02
Procedure
Note
Always mount the HMI device according to the operating instructions in this manual.
When mounting the HMI device, ensure that the labeling strips do not become jammed
between the mounting cut-out and the HMI device.
1. Insert the HMI device into the mounting cut-out.
2. Insert a mounting clamp into a recess of the HMI device.
3. Fasten each mounting clamp by tightening its screws.
The permitted torque is 0.2 Nm.
4. Repeat step 2 and 3 for all mounting clamps until all required clamps are tightened.
4.4 Connecting the HMI device
4.4.1 Connection sequences and lines
Requirement
● The HMI device must be mounted according to the specifications of these operating
instructions.
● Shielded standard cables
For additional information, refer to the Internet at:
Industry Mall (http://mall.automation.siemens.com
)
Connection sequence
Note
Failure to do so may result in damage to the HMI device.
Connect the HMI device in the following sequence:
1. With KP32F functional grounding
2. Power supply
3. Controller
Proceed in a reverse direction when disconnecting the connections.
