KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
47
Mounting and connecting the HMI device
4
4.1 "Mounting and connection of HMI device" checklist
The following steps must be taken when mounting and connecting the HMI device.
Test step Check
Check the scope of delivery (Page 47)
Mounting the HMI device (Page 47)
Connecting the power supply (Page 52)
Connect standard inputs/outputs (Page 54)
General (Page 55)
Connecting the EMERGENCY STOP button (Page 58)
Connecting the PLC (Page 61)
Switching on and testing the HMI device (Page 63)
4.2 Check the scope of delivery
Check the scope of delivery for completeness and visible signs of transport damage.
NOTICE
Do not use damaged parts
If you use defective parts from the items delivered, you may experience malfunctions.
If you find defective parts in the item delivered, contact your Siemens partner. Only install
undamaged parts.
4.3 Mounting the HMI device
Requirement
● For KP8, KP8F: Four mounting clamps.
For KP32F: Ten mounting clamps.
The mounting clamps are included in the accessory kit.
● The HMI device comes equipped with a mounting seal.
If the mounting seal is damaged, do not mount the HMI device.
