KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
65
Operator controls and displays
5
5.1 Front-sided control elements and displays
Operator control elements
There are illuminated pushbuttons on the front of the HMI device. The following figures show
the illuminated pushbuttons and the numbering of the associated LEDs.
KP8 and KP8F
KP32F





,QSXWE\WH[
,QSXWE\WH[
6ORW6ORW
,QSXWE\WH\
,QSXWE\WH\
x Input byte start address of slot 1
y Input byte start address of slot 2
