Overview
1.4 Structure of the KP32F
KP8, KP8F, KP32F
16 Operating Instructions, 11/2011, A5E03284305-02
Rear view
① Openings for labeling strips
② Bar for strain relief
③ PROFINET interfaces
④ DIP switch
⑤ Connector for the digital inputs
⑥ Connector for the digital inputs/outputs
⑦ Connector for the power supply connection
⑧ Connection for the functional grounding
⑨ Seal
