Technical specifications
9.7 KP8F – Encoder evaluation of the fail-safe channels
KP8, KP8F, KP32F
118 Operating Instructions, 11/2011, A5E03284305-02
The following evaluations are possible:
● No evaluation
Slot 2 was not set. No evaluation occurs.
)LUVWE\WH
6,/ 6,/
%LW %LW%LW %LW %LW %LW %LW%LW
● 1oo1 evaluation
The slot 2 was set with "1oo1 (1v1)-evaluation, one-channel". The connected sensor is
evaluated.
)LUVWE\WH
), ),
6,/ 6,/
%LW %LW%LW %LW %LW %LW %LW%LW
Bits 4 and 5 determine if the respective sensor contact is open or closed. The bits may
take on the following values:
– 0 = Open sensor contact
– 1 = sensor contact closed
● 1oo2 evaluation
The slot 2 was set with "1oo2 (2v2)-evaluation, EMERGENCY STOP". The
EMERGENCY STOP button is evaluated.
)LUVWE\WH
),
),
6,/ 6,/
%LW %LW%LW %LW %LW %LW %LW%LW
Bit 0 determines whether or not the EMERGENCY STOP button was pressed. The bit
can take on the following values:
– 0 = EMERGENCY STOP button pressed or error
– 1 = EMERGENCY STOP button not pressed
