Technical specifications
9.9 KP32F – Sensor evaluation of the fail-safe channels
KP8, KP8F, KP32F
Operating Instructions, 11/2011, A5E03284305-02
123
● FI.0.FI.1 1oo2, FI.2.FI.3 disabled
Slot 5 parameters were set to "FI.0.FI .1 1oo2, FI.2.FI .3 disabled". The EMERGENCY
STOP button is evaluated.
)LUVWE\WH
),
),
6,/ 6,/
%LW %LW%LW %LW %LW %LW %LW%LW
Bit 0 determines whether or not the EMERGENCY STOP button was pressed. The bit
can take on the following values:
– 0 = EMERGENCY STOP button pressed or error
– 1 = EMERGENCY STOP button not pressed
● FI.0.FI.1 1oo2, FI.2.FI.3 1oo2
Slot 5 parameters were set to "FI.0.FI.1 1oo2, FI.2.FI.3 1oo2". The EMERGENCY STOP
buttons are evaluated.
)LUVWE\WH
),
),
6,/ 6,/
%LW %LW%LW %LW %LW %LW %LW%LW
),
),
Bits 0 and 1 determine whether or not the EMERGENCY STOP button was pressed. The
bit can take on the following values:
– 0 = EMERGENCY STOP button pressed or error
– 1 = EMERGENCY STOP button not pressed
● FI.0.FI.1 1oo2, FI.2.FI.3 1oo1
Slot 5 parameters were set to "FI.0.FI.1 1oo2, FI.2.FI.3 1oo1". The EMERGENCY STOP
button and the connected sensors are evaluated.
)LUVWE\WH
),
),
6,/ 6,/
%LW %LW%LW %LW %LW %LW %LW%LW
), ),
Bit 0 determines whether or not the EMERGENCY STOP button was pressed. The bit
can take on the following values:
– 0 = EMERGENCY STOP button pressed or error
– 1 = EMERGENCY STOP button not pressed
Bits 6 and 7 determine if the respective sensor contact is open or closed. The bits may
take on the following values:
– 0 = Open sensor contact
– 1 = sensor contact closed
