9 Example — Unspecified Connection from a PC Application
119
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
Activity
2.
(In NetPro, you can enter the VFD name of the application (for example VFD 20) by
double-clicking on application and entering the required name.
To insert a connection, you must select the application.
Select the “Application” object and the select Insert
"
New Connection.
The following menu opens:
