18 DCOM Settings with the dcomcnfg System Program

257

Commissioning PC Stations - Manual and Quick Start

Release 5/2005

C79000-G8976-C156-07

18.3 ”Default Security” / ”Default COM Security” / ”COM

Security” Tab

Description of the Settings

In this tab (Windows 2000 : ”Default Security” ; Windows XP : ”Default COM

Security”, Windows XP+SP2 : ”COM Security”), you can specify the permissions

for DCOM. These properties are used by all COM objects that do not have their

own settings (settings made after selection in the “Applications” tab).

These settings make sure that only clients with the correct permissions can use

the server.
